Manual greenhouse washer

You operate the roof washer and the loading and unloading locks manually with the push button box. You can also move the platform with it.

Push buttons

Before using the push button box, first place the Roofmaster in front of the row and place the ramps in the gutter. As soon as the water pump is on, you can switch the Roofmaster on and off via the push button box. Thanks to the stops at the end of the gutter, the Roofmaster automatically returns to the platform.

On the growth

A manual greenhouse cover washer is very suitable for growers with a smaller greenhouse area who want to keep the cleaning under their own management. Also for companies with several smaller greenhouses that are not connected.

Customization

Growers grow different crops, have different greenhouses and all have different wishes when it comes to greenhouse roof washing. For this reason every Roofmaster we build is different. Since we develop all components in-house, even the most challenging customization is no problem for us. Every Roofmaster including displacement platform and accessories is tailor-made, installed on site and adjusted. Everywhere in the world.

Besseling Techniek
Besseling Techniek

Favorable delivery time, excellent service

Because have the full production process in-house we are not dependent on specific suppliers. As a result, we are able to link favorable delivery times to excellent service. Do you have a question or is there a malfunction? Then it is important to offer a solution as quickly as possible. Since we have developed every component of the Roofmaster ourselves, we have all the knowledge in-house.

Options manual greenhouse roof washer

Click on an option for more info.

Washing

  • Water pump truck

    The high-pressure pump truck has a capacity of 37 liters per minute and 55 bar, and the spray truck a buffer tank of 200 liters. The rear of the spray trolley can be equipped with manually operated hose and cable reels.

  • Air window detection

    With four switches, the air window detection system ensures that the roof washer stops as soon as the machine runs against an open air window. A window that is only slightly open is recognized by the switches.

    Besseling Techniek
  • Cup brushes

    The cup brush cleans the lower edge of the air vents. The brush can be moved, so that also the gutter edge and lower parts of the greenhouse cover are reached.

    Besseling Techniek
  • Gutter brush

    The gutter brush with adjustable rotation speed prevents blockage and ensures that the gutters are thoroughly washed. There is also a wide version available for shallow gutters. In addition to the gutters, this wider brush also thoroughly cleans the lower parts of the greenhouse roof.

    Besseling Techniek
  • Brush covers

    There are brush covers on all main brushes. These stop splashing dirt and water, so that the hood next to it stays clean. They also protect the brushes from the sun, which extends the life time.

    Besseling Techniek
  • Brush height adjustment

    The height of the brushes is easy to adjust. This option makes the roof washer suitable for several different greenhouse roofs.

    Besseling Techniek Borstelhoogteverstelling
  • Angle brush drive

    The angled brush drive provides the brush motor with an angled gearbox. This creates extra space between the roof washer and the greenhouse roof. This option is used for dilatations.

    Besseling Techniek
  • Gutter sprayer

    This high-pressure cleaner sprays all the dirt away from places where the gutter brush can not reach easily.

  • Dosatron dosing pump

    The Dosatron dosing pump makes it possible to add solvents to the water. For example, applied coatings and screening agents can be washed off the greenhouse roof.

    Besseling Techniek
  • Cable and hose guide

    Conductors for the reels ensuring even winding and unrolling of the electrical cable and water hose. This way cable and hose last longer.

    Besseling Techniek

Platform

  • Custom platform

    A customized implementation of the platform is desirable in some situations. The platform is then specially designed and manufactured for this situation.

    Besseling Techniek
  • Foldable platform

    If the Roofmaster is used for several greenhouses, a folding platform is the ideal solution. Because the legs of this platform can be retracted electrically, the system is easy to transport and move. Here too, a well-thought-out design guarantees that the platform can be reached safely.

    The version is equipped with a handrail and is supplied with a push-up ladder and four-point hoisting belt. This makes the system safe to lift and transport. The folding platform is also available as a contractor version (“loonwerker”). In this version the platform has been adapted so that it can be used in as many situations as possible.

    Besseling Techniek
  • Standard platform

    This is the most common version of the platform, also seen as a fixed setup. Generally speaking, this platform will hangs its entire life span on the facade of the same greenhouse. A well-thought-out design guarantees that the platform can be reached safely. It is equipped with a handrail and can be reached via a cage ladder.

Safety

  • Roof slide

    The roof slide makes it possible to move through the gutters more safely. This is possible both standing and sitting. The skis on the side are adjustable in width. This makes the cover slide suitable for any greenhouse.

    Besseling Techniek Dekslede
  • Set of protective equipment

    At Besseling Techniek we are convinced of the importance of working safely. That is why we have put together a set of protective equipment with a harness, helmet and safety line. These can be used in addition to the standard security interventions, such as the handrail and cage ladder.

Spray coatings

  • Spray trailer with two blending tanks

    The spray pump membrane pump has a capacity of 60 liters per minute and 40 bar. The trailer is equipped with two tanks of 1,000 liters each. Both tanks have a stirrer and injector to mix the mixture. The advantage of two tanks is that a new mixture is produced during spraying. The rear of the trailer can be equipped with a hose and cable reel.

  • Spray truck with two blending tanks

    The spray pump diaphragm pump has a capacity of 60 liters per minute and 40 bar. The spray truck is equipped with two 500-liter tanks, both of which have a stirrer mixer and injector to mix the mixture. The advantage of two tanks is that a new mixture is produced during spraying. The rear of the spray trolley can be equipped with a hose and cable reel.

    Besseling Techniek
  • Spray truck with blending tank

    The spray pump diaphragm pump has a capacity of 60 liters per minute and 40 bar. In addition, the tank has an injector to mix the spray mixture. The spray trolley is available in multiple versions: with a 600-, 1.000-, 1.500- and even 2.000-liter tank. The rear of the spray trolley can be equipped with manually operated hose and cable reels.

    Besseling Techniek
  • Push button box

    With the removable push button box, the roof washer and the loading and unloading legs can be operated manually. You can also move the platform manually with it.

    Besseling Techniek
  • Operating platform

    A safer way to drive along with the roof washer. The operating platform is equipped with a control panel.

    Besseling Techniek
  • Spray booms

    Ideal for greenhouse growers who not only wash the greenhouse roof, but also wish to apply coatings: the roof washer will be equipped with foldable spray booms that can spray screening agents and coatings to the greenhouse. They can spray three peaks at once: one and a half going towards the end, and one a half on the way back. This is done at a higher speed than washing, to ensure a high quality of works and to limit the closing of vents to a minimum of time.

    The spray booms are operated with the valves on the operating platform, where a button box is positioned as well.

    Besseling Techniek
